| Model number | EPRX-100PF |
| Brand | EPEPRO |
| Rated Current | 100A |
| Rated Voltage | 220V |
| Supply terminals | N,L1,L2,L3 |
| Rated supply voltage | AC 3 * 220V(N-L1/L2/L3) |
| Rated frequency | 40/50/60/70Hz |
| Umax setting range | 110 – 300V |
| Umin setting range | 80 – 220V |
| Auto – reclosing delay(Ton) | 1 – 600s |
| Return delay to priority phase | 1 – 600s |
| Switch delay to reserve phases | <0.2s |
| Voltage hysteresis | 5V |
| Overvoltage trip delay | 0.1s; ≥350V: 0.02s |
| Undervoltage trip delay | 0.1s; ≥350V: 0.02s |
| Voltage accuracy | <1% |
| Max. operating phase voltage | 350V |
| Rated operating current | 100A |
| Pollution degree | 3 |
| Electrical life | 10⁶ |
| Mechanical life | 10⁶ |
| Altitude | ≤2000m |
| Ambient temperature | -25℃ – +50℃ |
| Permissable relative humidity | ≤50% at 40℃ (without condensation) |
| Storage temperature | -25℃ – +55℃ |
| Conductor size | 0.5mm2 – 1mm2 |
