| Brand | EPEPRO |
| Model Number | EP-3PN 100A |
| Current rating | 100A |
| Rated operational voltage | 80-300V |
| Product dimensions | 7.53 × 5.83× 8.95cm |
| Material | Copper |
| Mounting type | Din Rail Mount |
| Circuit breaker Type | Standard |
About this item
| Product type | WIFI Miniature Circuit Breaker |
| Pole number | 3P4line |
| Rated frequency | 50/60Hz |
| Curve code | BC |
| Breaking Capacity | 6KA Ics=Icu |
| Uimp | 4kV |
| Tightening torque | 2.5N.m |
| Mounting support | 35mm DIN rail |
| operating temperature | -25℃ – +60℃ |
| Standard | IEC60898-1 |
