| Brand | EPEPRO |
| Model Number | BK65N 3P |
| Current rating | 6A / 10 A / 16 A / 20 A / 25 A / 32 A / 40 A / 50 A / 63 A (optional) |
| Rated operational voltage | 120V / 240V AC |
| Product dimensions | 5.4 × 7.4 ×8.2 cm |
| Material | Copper |
| Mounting type | Din Rail Mount |
| Circuit breaker Type | Standard |
About this item
Function: Designed to protect 110V, 120V, 220V, and 230V AC circuits from overload and short circuit damage; also suitable for control and isolation purposes.
Curve C: Magnetic trip range of 5-10 times the rated current.
Quality: Flame retardant shell, brass parts, moving and static contacts are copper parts, A-grade double gold, copper base point
Applications: Suitable for solar AC systems, RVs, household circuits, or other 50/60Hz AC systems.
Installation: Screw terminal connections with 35mm DIN rail mounting.
Technical Data
| Product type | AC miniature circuit breaker |
| Pole number | 2P |
| Rated frequency | 50/60Hz |
| Trip unit technology | Thermal-magnetic |
| Curve code | C |
| Breaking Capacity | 6KA Ics=Icu |
| Uimp | 4kV |
| Tightening torque | 2.5N.m |
| Electrical durability | 4000 cycles |
| Mechanical durability | 10000cycles |
| Mounting support | 35mm DIN rail |
| operating temperature | -25℃ – +60℃ |
| Standard | IEC60898-1 |
