EPR3-32X 1000VDC 32A DC Fuse Holder with LED Indicator, 10×38mm PV Fuse Base for Solar PV System

Product Description

EPR3-32X DC fuse holder is specially designed for photovoltaic solar DC system, energy storage and other DC power protection applications.

1. LED status indicator: Built-in LED indicator, green light keeps on when fuse is intact; when fuse blows, indicator changes to remind user quick fault location, greatly reduce maintenance time.
2. High safety performance: 1000VDC high DC voltage rating, up to 32A rated current, 33kA high breaking capacity. Adopt UL94-V0 flame retardant PBT housing, anti-aging, heat resistant and insulation.
3. Standard compatible: Fits standard 10×38mm gPV DC cartridge fuses, widely used in PV combiner box. Flip cover design, easy to replace fuse without extra tools.
4. Easy installation: DIN rail 35mm mounting, screw type terminal, stable wire connection. Compact 1P modular structure, save cabinet space.
5. Wide application: Solar PV combiner boxes, battery energy storage systems, DC power distribution, industrial DC control cabinets.
